WETHEPEOPLE – BATTLESHIP- RAW / ROJO CORAL – 2020

1.155,95 iva incluido

COLOR:  Raw / Rojo coral
TALLA: 20,75″
PESO: 12,57 kg
TRANSMISIÓN: Freecoaster – Raw dcha / Rojo izq
DETALE: Cubre bujes incluidos

Limpiar
SKU: N/D Categorías: , Etiquetas: , ,

Descripción

SPECIFICATIONS

Frame: WETHEPEOPLE «BATTLESHIP» frame, 4130 full crmo, hydroformed gussets, removable pivots & guides

Fork: WETHEPEOPLE  «BATTLESHIP» fork, post liquid heat-treated butted sanko tubing, 1pc cnc steerer, 24mm offset

Bars: ÉCLAT «STRANGLER» 4pc bar,  post liquid heat-treated 4130 crmo, 25.4mm clamping

Grips: ÉCLAT “SHOGUN” flangeless grips, ÉCLAT «Tech-Bolt» barends

Stem: ÉCLAT «DOMAIN», cnc alloy top loading stem, 48mm reach, 25.4mm clamping

Headset: ÉCLAT “Wave” int. headset, sealed bearing

Gyro: n/a

Lever: SALT “MOTO” alloy brake lever

Brakes: ÉCLAT «TALON» alloy u-brake rear

Cranks: WETHEPEOPLE “Logic” 22mm tubular 3pc crank crmo, 165mm, 48 spline

BB: WETHEPEOPLE “Compact” 22mm, press fit, sealed bearing

Pedals:  WETHEPEOPLE “LOGIC” nylon/fiberglass pedals

Chain: SALTPLUS “WARLOCK” half-link chain

Sprocket ÉCLAT «ELEVATE» 6061-T6 alloy, 25t sprocket & Nylon guard

Driver: 9t, 1pc freecoaster driver, sealed bearing

Front Hub: WETHEPEOPLE “HELIX” hub, sb, 3/8″‘s female bolts, 36h

Rear Hub: WETHEPEOPLE “HELIX» freecoaster hub, full sealed, 9t, 14mm axle, 36h

Hubguards: WETHEPEOPLE «HELIX» Nylon/Fiberglass (x2) front & (x2) rear hub guards

Front Rim:  ÉCLAT “BONDI» 38mm wide, flash welded double wall rim, 36h

Rear Rim:  ÉCLAT “BONDI» 38mm wide, flash welded double wall rim, 36h

Seat: ÉCLAT “BIOS” fat padded pivotal seat

Seat Post: WETHEPEOPLE “TEAM” pivotal seat post, 606-T6 alloy, 200mm long

Seat Clamp: WETHEPEOPLE “LOGIC” 4130 crmo seat clamp

Tires:  ÉCLAT “Predator” 2.30″ front & rear

Pegs: ÉCLAT «Venom» 4.8″, nylon-fibreglass x2

Weight: 12.57kg / 27.81lbs – without brakes, with pegs


FRAME GEOMETRY

A: Top Tube Length:  20.75”

B: Chain Stay Length: 13″ (12.7″-13.2″)

C: Head Tube Angle: 75.5°

D: Seat Tube Angle: 71°

E: Bottom Bracket Height: 11.7”

F: Stand Over Height: 9”


BAR GEOMETRY

G: Bar Rise: 9.1“

H: Bar Width: 29”

I: Bar Back Sweep: 11.5°

J: Bar Up Sweep: 2.5°
